Fluke 179 Multimeter

  • Mfr. Part No. FLUKE-179 EJKCT
  • Warranty
  • Manufacturer Fluke Industrial
Fluke 179 Multimeter
Fluke 179 Multimeter
Fluke 179 Multimeter
Fluke 179 Multimeter
Fluke 179 Multimeter
Fluke 179 Multimeter

Price

Per unit SGD 865.0 (inclusive of GST)

TRMS MULTIMETER W/BACKLIGHT & TEMP (ENG JPN KOR CHI TH) Local (Singapore) manufacturer warranty : Limited Live time on Main unit 1 Year on Accessories “lifetime” is defined as seven years after Fluke discontinues manufacturing the product

Quantity

Add To Favourites

Remove from Wishlist

Product Details

Fluke 179 True-rms Digital Multimeter with Temperature

The Fluke 179 True-rms Digital Multimeter is the industry-standard troubleshooting tool for electrical and electronic systems. This incredibly versatile multimeter makes a perfect front-line troubleshooting tool with an input protection rating of CAT III 1000 V CAT IV 600 V. The built-in temperature measurement with the included thermocouple analog bar graph and backlit digital display make it easier to take the measurements you need.

A full set of basic and advanced troubleshooting capabilities including:

  • Manual and automatic ranging
  • Display Hold and Auto Hold
  • Min/Max-Average recording
  • Voltage measurements to 1000 V AC or DC
  • Current measurements to 10 A AC/DC
  • Resistance to 50 MΩ; capacitance to 10 000 μF frequency to 100 kHz; temperature from -40 ℃ to 400 ℃

All of these features come paired with a lifetime warranty.

What’s in the box:

  • 179 Digital Multimeter
  • 80BK Temperature Probe
  • Installed 9V battery
  • Test leads
  • Quick Reference Guide

Key features

  • 1000V AC/DC; 10A AC/DC (with test leads and current jacks); resistance to 50 MΩ; capacitance to 10 000 μF frequency to 100 kHz; temperature from -40 ℃ to 400 ℃
  • Robust fast and accurate with manual and automatic ranging Display Hold Auto Hold and Min/Max-Average recording
  • Backlit digital display analog bar graph and built-in temperature measurements with included thermocouple.

Product Specification

Specifications
Voltage DC Accuracy1 ±(0.09% + 2)
Max. resolution 0.1 mV
Maximum 1000 V
Voltage AC Accuracy1 ±(1.0% + 3)
Max. resolution 0.1 mV
Maximum 1000 V
Current DC Accuracy1 ±(1.0% + 3)
Max. resolution 0.01 mA
Maximum 10 A
Current AC Accuracy1 ±(1.5% + 3)
Max. resolution 0.01 mA
Maximum 10 A
Resistance Accuracy1 ±(0.9% + 1)
Max. resolution 0.1 Ω
Maximum 50 MΩ
Capacitance Accuracy1 ±(1.2% + 2)
Max. resolution 1 nF
Maximum 10,000 µF
Frequency Accuracy1 ±(0.1% + 1)
Max. resolution 0.01 Hz
Maximum 100 kHz
Temperature Accuracy1 ±(1.0% + 10)
Max. resolution 0.1°C
Range -40°C / 400°C
1. Accuracies are best accuracies for each function
Environmental Specifications
Operating temperature -10°C to +50°C
Storage temperature -30°C to +60°C
Humidity (without condensation) 0% – 90% (0°C – 35°C)
0% – 70% (35°C – 50°C)
Safety Specifications
Overvoltage category EN 61010–1 to 1000 V CAT III
EN 61010–1 to 600 V CAT IV
Agency approvals UL, CSA, TÜV listed and VDE Pending
Mechanical and General Specifications
Size 43 x 90 x 185 mm
Weight 420 g
Warranty Lifetime
Battery life Alkaline ~200 hours typical, without backlight
